مميزات خاصة

Product Features: The DC shunt resistor features two holes on either side for secure mounting, with nuts provided for circuit connection.
Product Material: Current shunt resistors are manufactured from rust-proof plated copper, ensuring stable performance and durability.
User-Friendly Operation: This ammeter utilises a shunt resistor, offering compact dimensions and straightforward operation. It is rated for currents exceeding 50A and operates at temperatures not exceeding 120°C.
Product Connection: The shunt must be connected in parallel with an ammeter (moving-coil ammeter) to bypass current. Typically, the two external terminals connect directly to the power circuit, while the two internal terminals connect in series with the ammeter.
This product protects the ammeter and assists the ammeter in measuring very large currents.

وصف

A 'must have' component for DC current meter
It could be used either in a digital or an analog meter
The shunt is used to multiply the measuring range of current of measuring
It can be used to connect to a 50Amps/100Amps ect DC current meter
Specifications:
Current: 10A/20A/30A/50A/100A
Voltage Drop: 75mV
al Condition : -40~+60c
Relative Humidity: 95%(35c)
Shock Endurance: 80-120 times/mins
Overreacting Capacity: 120% (of rate current)
Size (L*W*H):12 x 2.5 x 1.8cm/4.72"x0.98"x0.70"(approx)
Quantity: 1 pc
Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item.
Size : 100A/50A/30A/20A/10A 75mV shunt
Type : 100A/50A/30A/20A/10A 75mV shunt
Model Number : 100A/50A/30A/20A/10A 75mV shunt
DIY Supplies : Electrical
Style : 100A/50A/30A/20A/10A 75mV shunt
Output Voltage : 100A/75mV 50A/75mV Current Meter Shunt
Origin : China
