Specification: MIL-DTL-5015
Sealing: Meets IP67
Shielding: Yes
Connector Type: Circular
Connector Style: Plug
Mounting Type: Cable
Orientation: Straight
Number of Contacts: 35
Contact Style: Pin
Termination Method: Solder
Insert Arrangement: 28-15
Contact Size: 35#16
Contacts Supplied: Yes
Contact Material: Copper Alloy
Contact Plating: Silver
Shell Material: Aluminum Alloy
Shell Plating: Olive Drab Chromate over Cadmium
Shell Color: Olive Drab
Insert Material: Neoprene
Grommet Seal Material: Neoprene
Amperage Rating: 13A
Operating Voltage DC: 700
Operating Voltage AC: 500
Operating Temperature: -67 to +257 (-55 to +125)
Contact Mating life: 500
RoHS: No
Insert Rotation Keying:
