325-L SERIES Lever Acting Design for 2 psi Piping Systems
Maxitrol's 325-L series line pressure regulators are for 2 psi piping systems. 325 series regulators are for use on residential, commercial, and industrial applications. The 325 series features a high leverage linkage assembly to deliver positive dead-end lockup. The regulators are capable of precise regulating control from full flow down to pilot flow.
Specifications
✔ Pipe Sizes: 3/8” to 2” threaded connections with NPT or ISO7-1 threads.
Optional: 1/8” NPT outlet pressure taps on 325-7, 325-9, and 325-11.
✔ Housing Material: Aluminum.
✔ Mounting: All models with the exception of the 325-11L are suitable for multi-positional mounting. The 325-11L is to be mounted in a horizontal upright position only. If a ® or ® is installed, mount in an upright position only.
NOTE: All Maxitrol gas pressure regulators should be installed and operated in accordance with Maxitrol Safety Warning Instructions (see GPR_CSA_2PSI_MI_EN.FR).
✔ Certifications: ANSI Z21.80/CSA 6.22 Line Pressure Regulators.
✔ Gas Types: Suitable for natural, manufactured, mixed gases, liquefied petroleum gases, and LP gas-air mixtures.
✔ Rated Inlet Pressure: CSA Certified: 2 psi (13.8 kPa)
✔ Maxitrol Tested: 10 psi (69 kPa)
✔ Emergency Exposure Limits: 65 psi (450 kPa) (inlet side only)
