CV181-TII: Medium U Dual Triode for Voltage Amplifier Circuits
Filament voltage:
Ultra high 6.3 volts
0.6A current
Static parameters
Voltage 90 250 V
Voltage 0 -8V
Current 109 mA
On resistance3 2.6 mA/V
6.7 7.7 thousand
20 20
When Ug=-12.5V, Ia_1.3mA
Ia=-10uA when Ug -7 - 18V
Extreme Rating
A1 magnification (each side)
450 volts
Current - 20mA
Pascal
Pa (No. 1+No. 2) 7w
Type 1M
Rated voltage ±100V
