Nominal Coil Voltage: 24VDC
Contact Form: SPDT
Contact material: AgSnO alloy
Operate time(1) : 15ms Max.
Release time(1) : 10ms Max.
Insulation resistance(1): 1000 MΩ Min. (DC 500V)
Contact Rating:40A
Operating ambient temperature:-55~+70°C (no freezing)
Weight: Approx.27g
Package Content: 1 x832HA-1C-F-C 24VDC
Attention:
Do not switch the contacts without any load as the contact resistance may become increased rapidly.
To assure optimum performance, avoid the relay from dropping, hitting, or other unnecessary shocks.
