kimllier 2 Spool Hydraulic Valve 11GPM 3625PSI Hydraulic Directional Control Valve SAE Ports Double Acting Valve

KWD 26.500
Brand
kimllier
Category
Fittings
Weight
7.8 kg
Size2 Spool 11 GPM
StyleSAE
– 1 +

Special Features

  • This loader control valve come with 2 spools, with cast iron construction for long-time use.
  • The relief valve range is up to 3625 PSI and the maximum flow is up to 21 GPM. A & B Work Ports: 10 SAE O-Ring (7/8-14) Thread, Inlet Port: 10 SAE O-Ring (7/8-14) Thread, Outlet Port: 12 SAE O-Ring (1-1/16) Thread.
  • The check valve in the valve body ensures that the hydraulic oil does not return, and the overflow valve in the valve body can adjust the working pressure of the hydraulic system.
  • Hydraulic control valve used to operate double-acting cylinders. All standard spools are spring-returned and can be reset to the neutral position. There are springs at the bottom of the handles that make the joysticks easy to control.
  • Fit for small tractors, tractors loaders, log splitters, and etc.

Description

2 Spool Hydraulic Valve 21 GPM 3625 PSI Hydraulic Directional Control Valve w/Joystick SAE Ports Double Acting Valve

Features:
Durable cast iron construction provides long-term usage.
The relief valve range can reach up to 3625 PSI and the maximum flow is up to 21 GPM.
All spools are standard double acting with spring return to neutral position which are ideal for double acting cylinders.
Used for small tractors, tractors loaders, log splitters and other mobile.

Specification:
A & B Work Ports: 10 SAE O-Ring (7/8"-14) Thread
Inlet Port: 10 SAE O-Ring (7/8"-14) Thread
Outlet Port: 12 SAE O-Ring (1-1/16") Thread
Max Operating Pressure: P = 3625 PSI, T = 725 PSI, A & B = 4350 PSI
Nominal flow: 21 GPM
Relief valve: Adjustable

Package Includes:

1 x 2 Spool 21 GPM Hydraulic Directional Control Valve
