Description:
Single-row, pre-lubricated, normal accuracy.
Single row angular contact ball bearings are designed to accommodate axial loads in one direction only.
This type of bearing is typically adjusted against a second bearing.
Their bearing rings have an upper and a lower shoulder and are non-separable.
Chromium Steel (GCr15) made with heat treating, provides high and uniform hardness, good wear resistance, and high contact fatigue performance.
Suitable for use in commercial and industrial applications including pumps and compressors, gearboxes, and printing machines, among others.

Specification:
Model: 7001AC
Type: Open Type
Inner Race/Outer Race Material: Chrome Steel (GCr15)
Cage Material: Nylon
Inner Diameter (d): 12mm
Outer Diameter (D): 28mm
Thickness (B): 8mm
Dynamic Load Rating (Cr): 5.4kN
Static Load Rating (Cor): 2.75kN
Contact Angle: 25°
Accuracy Class: P0 (ABEC-1)
Noise Level: Z1
Number of Pack: 5 Pcs
