USB Microscopes
Specifications :
Optical System: infinity corrected
Nosepiece: reversed, ball bearing quintuple
Head: gemel type trinocular head, 30-degree inclined
Eyepiece: high eye-point eyepieces, PL10X22mm, 25X9mm
Objectives: infinity plan objective 4X, 10X, 20X, 40X (spring), 100X (spring, oil)
Focusing: low position coaxial focus system
Focusing Range: 1-3/16" (30mm)
Interpupillary Adjustment Range: 2-3/16" - 3" (55-75mm)
Mechanical Tube Length: 6-5/16" (160mm)
Mechanical Stage: 8.5" x 5.9" (216mm x 150mm)
Stage Traveling Range: 2.9" x 2" (75x50mm)
Focusing Rang: 0.95" (24mm)
Division of Fine Focusing: 0.00003935" (0.001mm)
Illuminator: Built-in Kohler LED illumination system
Condenser: N.A. 1.25 achromatic condenser
Illumination: Kohler, LED
Power Supply: 90V-240 wide voltage, CE certified
Built in measurement capabilities
Packing List :
Trinocular Compensation-Free Head
Microscope Body with Frame, Base, and Kohler Illumination System
Five High Quality DIN Plan Achromatic Objectives: 4X, 10X, 20X, 40X and 100X
One Pair of Extreme Widefield PL10X Eyepieces
One Pair of 25X Eyepieces
One Dust Cover
==========
Battery Included : No
Hign-concerned Chemical : None
Magnification Ratio : 1500X - 3000X
Drawtube : Trinocular
Material : Metal
Origin : Mainland China
Model Number : T720QC
Theory : Biological Microscope
