مميزات خاصة

Wide Applicability: Suitable for various scenarios, this power supply module can be used in a wide range of applications, providing power to different types of circuits or devices.Enjoy the versatility and flexibility of powering multiple devices, ensuring efficient performance in diverse settings.
Input voltage: 5V-30V;Output voltage: 3.3V/5v;Current output: peak 3A, 1.8A long time;Switching Frequency: 1.5 MHz (highest);Output ripple: 30mV (no-load);Output Current: 3a (Max)
Compact Size: With its small and compact form factor, this buck converter module offers convenience in terms of size and ease of use.Its compact design allows for seamless integration into different systems or device configurations
Built with precision and using high-quality materials, this outputs buck converter board boasts excellent durability and a long lifespan.Trust in the reliable performance and longevity of this module, ensuring consistent power supply for your devices.
With a conversion efficiency of up to 96%, this voltage regulator module ensures minimal power loss during the voltage step-down process.Experience optimal energy utilization and reduced heat generation, maximizing the efficiency of your power supply system.

وصف

Specification:
Type: Voltage Regulator
Model Number: Step Down Converter Board Module
Input Voltage: 5v~30v (Must Be Higher Than The Output Voltage) Preferably Below 28v.
Output Voltage: 3.3v/5v, Other Voltage Values Can Be Customized.
Output Current: 3a (Max) Normal 1.61.8a Over Plus Heat Sinking
Conversion Efficiency: 96% (Maximum)
Output Ripple:
Output Accuracy: ±0.1v
No-Load Current:
Operating Temperature: -40℃~+85℃
Operating Humidity: 20%~90
Size: 17*12*4mm(L*W*H)
Pcb Layers: 2 Layer Board
Shutdown Function: Not Supported
Heat Dissipation Mode: Natural Heat Dissipation
Installation: Wiring
Whether With Isolation: Without Isolation
Production Process: Machine Labeling, Reflow Soldering
Design Aging Standard: 720 Hours Without Failure
Factory Aging Standard: 72 Hours Without Failure
Service Life: 30,000 Hours Without Failure (Output Current Does Not Exceed The Rated Value)
Inspection Standard: All Test (Factory Test + Storage Test)
Output Voltage: 3.3v/5v/9v/12v
Product Size: 17.00x12.00x4.00mm/0.67x0.47x0.16inch
This power supply module is a power supply that can be directly mounted on a printed circuit board and features a power supply for application-specific integrated circuits (ASICs), digital signal processors DSPs, microprocessors, memories, field-programmable gate arrays (FPGAs), and other digital or analog loads.
Note:
1. Input voltage preferably below 28V.
2. Normal current 1.6-1.8A over please add heat sink.
