UV Energy Meter LS131 UVA radiometer Light Meter For the power and energy value of 365 385 395 405nm UV LED lamp

LS131 UV Energy Meter Characteristics:
1. It can detect the intensity and energy of UV UV LED light source at the same time. It has rich statistical functions and can display the real-time power value, maximum power value, energy value and measurement time at the same time.
2.The LS131 UV energy meter has a power curve diagram, which can analyze the light intensity distribution of the UV light source through the power curve diagram.
3.High temperature resistant design, can run in the environment of 100 degrees for a long time. We also provide high temperature resistant protective cover for customers to choose.
4.The front detector design facilitates data reading during the test.
5.High-speed acquisition of 2048 times / second makes the test data more accurate. With the provided PC software, each test data can be exported to EXCEL form after connecting to the computer, and a test report can be nerated. The test report can be printed as a PDF file for archiving.
6.Wide spectral response, can measure UV LED light sources of various wavelengths such as 365nm, 375nm, 385nm, 395nm, 405nm.

LS131 UV Energy Meter Parameters:
Spectral ran
340nm-420nm, calibrated at 395nm
Irradiance measuring ran
0-40000mW/cm²
Irradiance resolution
1mW/cm²
Energy measuring ran
0-999999mJ/cm²
Energy measuring accuracy
±10%,±5% (typical)
Sampling speed
2000 times/second
Irradiance data stora interval
32 times/second
Recording period
32 minutes
Display
240*160 Dot matrix LCD
Dimension
160mm × 75mm × 13mm (L*W*H)
Weight
303 g
