Phase Monitoring Relays
Product Parameters:
1.Model number:SVP-916 63A
2.Power supply: AC 230V or 120V 50/60Hz
3.Max.Loading power: 1~63A Adjustable(default:63A)
4. Over-voltage protection value range:221V~300~OFF(default:280V) or 130-150V-OFF(default:140V)
Over-voltage recovery voltage range:220V--299V(default:250V) or 131-149V(default:135V)
Over-voltage protection action time:0.1s~10s(default value:0.1s)
5.Under-voltage protection value range:219V--150V-OFF(default:160V) or 100-80V-OFF(default:90V)
Under-voltage recovery voltage range:151V--220V(default:180V) or 81-99V(default:95V)
Under-voltage protection action time:0.1s~10s(default:0.1s)
6.Over-current adjustment range:1-63A(default: 63A)
Over-current action range:0.1~512 second (default:5.0s)
7.Recovery delay time:2s~120s(default:60s)
8.Power-on delay time:2s~10s(default:2s)
10.Electric machinery life : 100,000 times
11.Installation:35mm DIN rail
==========
Type : Voltage Protector
Type : Voltage relay
Model Number : SVP916-63A
Is Smart Device : No
Rated Voltage : 220V
Size : 36*65*85mm
Passing Max Current : 63A
Function : Voltage Protector
Voltage Protector : Over and Under
Protection Value : Adjustable
Power Supply : 230V or 120V AC, 50/60Hz
