Power Supplies
Laboratory 400V adjustable 5A stabilized voltage workbench switch power supply testing aging maintenance power supply
Feature:
(1) Voltage and current can be preset;
(2) Voltage, current, power, equivalent resistance 4 Windows 4 high precision display at the same time;
(3) over voltage, over current, over power, over temperature, cornet 5 double protection;
(4) ON/OFF output on-off switch;
(5) SENSE compensation interface is optional at the back;
(6) It is equipped with communication serial port RS232 in the rear, and the upper computer software can control the output on and off and read the output voltage and current value;
Rated output (0--40)
Voltage stability: 2%
Current stability: 0.5%
Load stability: 0.5%
Ripple and noise: 1% (RMS)
Output voltage preset accuracy: 0.1V
Output constant current preset accuracy: 0.1A
Altitude:2000m
Ambient temperature: 5~ 40
Ambient temperature: -20~ 80
Relative humidity: 80%
Power input: A220V±10%, 50Hz (or A110V input or A100V/220V manual switching) Reminder: 110V input or 220V input can be fixed within 900W; 110V input is not supported above 1000W
Accessories: manual, power cord, certificate
Product Description
==========
is_customized : no
Output Type : SINGLE
Input Voltage : AC220V±10%
Output Frequency : 50/60Hz
Product Name : laboratory power supply
Application : System/Laboratory/Charge Battery/Motor Fields/Lab
Type : Regulated Voltage & Current output
Display Type : LED Digital Individually Displayed
Color : White
Dimension : 330(D)250(W)155(H)mm
Name : power supply
