DIYmall GX3255BLS Digital Servo 7.4V 55KG High Torque Full Metal Helical Gear Brushless Motor IP68 RC Robotic Servo for 1/8 1/10 Cars

Description
product size: 40.5*21*41.7mm
Net weight of product: 90g
Operating Voltage: 5.0-7.4V DC
Standby Current: ≤ 20mA
Stall Current 5.0V: ≤ 6A
Stall Current 6V: ≤ 7A
Stall Current 7.4V: ≤ 8A
No Load Speed 5.0V: ≤ 0.1 sec/60°
No Load Speed 6V: ≤ 0.09 sec/60°
No Load Speed 7.4V: ≤ 0.08 sec/60°
Max.Torque 5.0V: ≥ 45 kgf.cm
Max.Torque 6V: ≥ 50 kgf.cm
Max.Torque 7.4V: ≥ 55 kgf.cm
Rotating Direction: ccw(500~2500us)
Operating Travel Angle: 360° continuous rotation (500~2500us)
Neutral Position: 1500us
Reduction ratio: 1:299
Dead Band Width: ≤ 2us
Operating Temperature Range: -20℃~+80℃
waterproof rating: IP68

Features
- Metal Gear
- Semi-metal case
- Brushless motor
- IP68

Packing list
1 x Servo with servo accessories
1 x color box packing
