Replace the Old Blower Fan on 3D Printer: Ideal upgrade / replacement 40 mm 24 volt blower fan for 3D printer (hot end or part cooling) and other 24V applications (combo amplifier, small humidifier); Fit for CR-10S Pro V2, CR-10S Pro, CR6-SE, Ender 3, Ender 3 V2, Ender 3 S1, Ender 5 Pro, Ender 5 Plus and so on
Brushless DC Blower: 40 mm small turbo blower fan is constructed of PBT material; Built-in high end pure copper coil dual ball bearings, this 3D printer part cooling fan can run continuously for 50,000 hours at high speeds without hassle or concern
3.3 FT Long Cable Wire: XH2.54 2Pin Connector with 1 meter (3.3 ft) cable wire for power supply; make sure positive (Red wire) and negative (Black wire) poles are in right place and match up to your 3d printer motherboard; Whether you want to replace a broken fan, improve overhang and bridging distances, or improve the airflow towards your parts, this 4020 blower fan upgrade is something that can get you there
4020 Blower Fan 24V Specs: Size: 40 x 40 x 20 mm (1.57 x 1.57 x 0.79 inches) | Hole to Hole Distance: 32 mm (1.26 inches) | Rated Voltage: 24V | Rated Current: 0.07 A | Power: 1.5 W | Speed: 6500 RPM | Noise: 32.5 dBA | Airflow: 3.67 CFM | Static Pressure: 0.46 In H2O; please confirm your 3D printer model before ordering
Easy to Use: Includes 2Pcs DC 24V 40x40x20mm Blower Fans and 6pcs mounting screws and nuts; Startup Voltage: 3V; Opearating Voltage: 14 to 26V (If over 26v, it also can wirk, but will affects the fan life); providing effective cooling and improved print quality for essential components

وصف

4020 blower Description

This is a 3D printer cooling blowing fan, which is made of PBT plastic material. It is excellent for cooling heatsinks on hot ends, prints, or other cooling needs, bearing is high precision, long life and low noise. Containing long life dual ball bearings, the fans can be run continuously for 50,000 hours and be mounted in any direction. 40mm blower fan 24v which perfect for ender 3 fan upgrade. Fit for Ender-3、Ender-3 Pro、Ender-3S、Ender-3 v2、Ender-3 Max、Ender-5、Ender-5s、Ender-5 Pro、 Ender—5 Plus、Ender_6、CR-5 Pro H、CR-X、CR 10S Pro V2、CR-6 SE、CR-6 Max、CR-30 (Installation Position for Nozzle); Whether you want to replace a broken fan, improve overhang and bridging distances, or improve the airflow towards your parts, this 4010 blower fan upgrade is something that can get you there.

Porduct Dimension
Total Dimensions: 1.57 x 1.57 x 0.79 inches (40 x 40 x 50 mm )
Hole to Hole Distance: 1.26 x 1.26 inches (32 x 32 mm)
Screw Hole Size: Ø 0.13 inches (Ø 3.2 mm)
Cord Length: 3.3 feet (1 meter)

Product Performance and Technical Specs
Total Airflow: 3.67 CFM
Total Noise: 32.5 dBA
Fan Speed: 6500 RPM
Operating Voltage: 14 to 26V DC
Power: 1.5 W
Current: 0.07 Amp
Static Pressure: 0.46 In-H2O
Operating Temperature: 14 to 167°F
Fan Bearings: Dual Ball
Life Expectancy: 50,000 Hours

Note:
1.Transition: 1cm=10mm=0.39 in.
2.Please allow 0-1cm error due to manual measurement. please make sure you do not mind before you ordering.
