Lag distance: less than 10% of the detection distance
Detection of objects: Magnetic metal (detection distance is reduced when non-magnetic metal)
Response frequency: DC: 0.5KHZ AC; 25Hz
voltage: DC type: DC6-36V pulsation (P-P) 10% or less AC type: AC90-250V50/60Hz
Withstand voltage: AC1000V50/60Hz1min between the live part and the housing
Effect of voltage: When the rated power supply voltage range is within 15% of the specification of the power supply voltage, the detection distance changes within 15% of the range.
Current consumption: N, P type; 13mA or less; D type: 0.8mA or less
Control output: N, P type; 300mA or less; D type; 200mA or less
Circuit protection: N.P.D type: reverse connection protection, surge absorption protection, load short circuit protection
Use ambient temperature, humidity: -25 ° C - +65 ° C (but not frozen) 35-96% RH
Effect of temperature: -25°C-+65°C (in the temperature range, when the rated power supply voltage is changed, the detection distance changes within 15%)
Insulation resistance: 50MQ or more (with DC500V) charged part together with the housing
Vibration: Durability: 10-55Hz complex amplitude 1.5nm, X, Y, Z direction for 2 hours each
Impact: Durable: 500m/s (about 50g), X, Y, Z direction 10 times each
Protection level: Ip67
Material: Housing: brass nickel plated detection surface; heat resistant ABS
