Cooling Pads
Below is the installation guide for the radiator. (The heatsink and fan in the manual are for illustration only and are not included in this product.)

Specification:

Colour: Black

Applicable objects: Multi-platform

Radiator Type: Water Cooler/Liquid Cooler

After-sales service: Three Guarantees

Dimensions: 125*92*29(H)mm (excluding outlet height)

Model: SR-L90F95

Material: Aluminum

Dimensions: 125*92*29(H)mm

Net weight: 200 grams

Fin density: 18 pieces/inch

Tube number: 9 tubes

Sealing technology: aluminum vacuum brazing

treatment: environmentally friendly black paint

Outlet diameter: 9.5mm

Water pipe: suitable for inner diameter 6-8mm silicone pipe with clamp

Warm reminder: Please always pay attention to the length of the screw, otherwise it will damage the bottom of the radiator.

packing list

Aluminum radiator*1

Screw*1 set
