1.DB25 Male to Male Connector with Metal Heads:
Both ends of the DB25 Male to Male cable use metal connectors to enhance durability.
2. Connection Sequence:
All 25 pins are connected in a straight-through configuration, with the following sequence: 1-1, 2-2, 3-3, ..., 24-24, 25-25, G-G.
3.Bare wire color sequence comparison table:
1-black, 2-brown, 3-red, 4-orange, 5-yellow, 6-green, 7-blue, 8-purple, 9-gray, 10-white, 11-black & white, 12-brown & white, 13-pink, 14-light green, and 15-light blue
4.Interference resistance:
Features 26 AWG tinned copper conductors and gold-plated pins to ensure smooth connection performance. A metal braided layer and aluminum foil shielding structure prevent external interference, ensuring safe and stable connections.
5.Cable Material:
The DB25 cable is made of PVC material, featuring wear-resistant and damage-resistant properties, easy to bend, and suitable for daily use.OD:9.0mm
6.User-Friendly Design:
Plug-and-play functionality, no soldering required, making it user-friendly for beginners.
7.Wide Applicability:
The DB25 serial cable can connect various devices, such as computers, printers, CNC machine tools, and automation machinery, etc.
Product Specifications:
Cable Type: DB25 Male to Male Extension Cable with Metal Connector
Length: 3 Feet
Wire Gauge: 26 AWG
