ATO/ ATC Automatic Reset Circuit Breakers 5A 5 Pack，UL-Rated 94V0 thermoplastic body and Tin-plated copper alloy terminals
Termination: 5.2mm wide blades compatible with ATO/ ATC type fuse blocks， Compliances: SAEJ553,SAEJ1171 Ignition protected
Function: Auto Reset circuit breaker low profile ATC/ATO Fuse is designed to provide overcurrent and short circuit protection, preventing damage to electrical systems and equipment， Auto Reset circuit breaker has a long lifespan, with the ability to be reset and reused multiple times, providing a cost-effective solution for protecting electrical systems and equipment
Perfect Replacement: The same size blade design of the fuse makes it easy to replace the original fuses in your fuse panel, it's compatible with the regular/standard ATO and ATC fuse slots to replace the blown ATO/ATC fuses. Each fuses are color-coded on the plastic housing, and the carved amp rating (5A/10A/15A/20A/25A/30A) are figures on the fuses for easy identification
Wide Application: Suitable RV, Boat, Car, Solar Panels, Truck, Motorcycle, Excavator, etc. Widely apply in a variety of different applications

وصف

Specification:
Serie: E37 Circuit Breakers
Reset Type: Auto Reset
Material: Insulating flame retardant material
Operating Temperature Rating: –40°F (–40°C) to 185°F (85°C)
Storage Temperature Rating: –40°F (–40°C) to 260°F (125°C)
Materials: UL-Rated 94V0 thermoplastic body. Tin-plated Copper alloy terminals
Termination: 5.2mm wide blades (ATC Type)
Compliances: SAEJ553; SAEJ1171 (Ignition protected)
Rated Current: 5A/10A/15A/20A/25A/30A
Interrupt Capacity: 14V DC
Dimension: 1.16x0.78x0.25 inch( 29.5x19.7x6.2 mm)
Interrupt Capacity: 2000 Amp @ 14V DV

Product Features:
1. Quality Materials, Shell uses UL-Rated 94V0 thermoplastic body and terminals use Tin-plated copper alloy.
2. Overload Protection, There are two metal sheets inside. When the current is overloaded, high temperature will separate the metal sheets and the current disconnect the connection.
3. Automatic Recovery, When the current is overloaded and automatically disconnect, it can automatically recover within about 60s. 4. Wide application, Suitable RV, Boat, Car, Solar Panels, Truck, Motorcycle, Excavator, etc. Versatile design for various applications.

Package Includes:
5xCircuit Breakers Protector E37 5A
