Specification

Capacity
±10000N.m

Display Range
-99999-99999

Speed Capacity
15000rpm

Maximum torsion angle
2.60*10rad(0.149°)

Speed Signal
120/60/10/rpm, 4-20mA, 0-20mA, 0-5V, 0-10V

Moment of inertia
0.38kgcm

Non-Linearity
0.5%F.S.

Torsion constant
3.85x10N.m/rad

Repeatability
0.2%F.S.

Stability per year
0.3%/year

Creep(30min)
0.03%F.S/30min

Material
Stainless Steel

Zero Balance
±2%F.S.

Working voltage
DC 24V 0.2A

Temp Effect on Zero
0.01%F.S./10

Safe Overload
200%

Current consumption

Response time
0.6ms(50%)

Cable Specifications
5*300cm

Acquisition Speed
550/1200/m

OperatingTemp Range
-10-500-85%RH

Load resistance
2k

This model is available with the following output configurations: RS485 (communication) + 0–10 V, RS485 + 4–20 mA, or RS485 + 0–5 V. Please contact customer service or specify your requirements; otherwise, we will supply the default version with RS485 communication + 0–5 V.
