All-in-One Protection Saves Cost & Prevents Fire – Instead of buying separate GFCI and surge protectors, this 2-Pole RCBO combines both at a fraction of the cost. It guards your 240V heavy-load circuits (EV chargers, dryers, HVAC) against leakage currents, voltage spikes, and short circuits – significantly reducing the risk of electrical fires and appliance damage.
Type A+AC Dual Leakage Detection – Detects both AC and pulsating DC residual currents from modern electronics, preventing nuisance trips while ensuring no leakage goes unnoticed. This keeps your appliances safe and your home protected from hidden ground faults that could ignite fires.
20kA Surge Suppression for Appliance Longevity – Built-in SPD reacts in under 25ns to clamp lightning-induced or grid-switching surges, shielding sensitive control boards (EV onboard chargers, smart dryers, variable-speed HVAC) from costly damage. Extends appliance life and avoids fire hazards from overheated components.
Instant LED Diagnosis & Tool-Free Mounting – Green/Red LEDs show power, ground, and surge health at a glance – no multimeter needed. Quick snap onto 35mm DIN rail saves installation time and labor costs, making professional-grade protection affordable for DIY users.
Certified Safety with Monthly Test Button – Meets international standards. Press the test button monthly to verify both GFCI and surge functions are working. Perfect for garages, workshops, laundry rooms, and outdoor sheds – anywhere you need reliable, cost-effective protection against leaks and surges.

وصف

DZ47LED-2LNE Residual Current Circuit Breaker (Lightning Residual Current Circuit Breaker), is miniature leakage circuit breaker with lightning protection device. It is suitable for distribution network with AC230V. For Lightning protection, overvoltage protection, overcurrent protection, leakage protection, short circuit protection, circuit isolation.
DZ47LED-2LNE Lightning Residual Current Circuit Breaker performance standards: GB16917.1 "Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs)-Part 1: General rules", GB 18802.2, IEC61643-1 and GB 500057 "Design code for protection of structures against lightning".
Rated Current：60A
Poles: 3P(L1+L2+N)+PE
Rated Voltage Ue:120/240V AC (Split-phase)
Insulation Voltage Ui: 500V
Rated Frequency: 50/60Hz
Rated sensitivity I△n: 30mA
Short-circuit current Inc=l△c: 4500A
Break time under I△n: ≤0.15
Residual current protection type: Electronic
Terminal size top/bottom for cable: 25mm²
Tightening torque：2.5Nm
Thermo - Magnetic Release Characteristic：C-Curve (5-10In)
Electrical Life: 4000
Mechanical Life: 10000
