مميزات خاصة

High Precision: Measures torque up to 3000N.m with a non-linearity of 0.5% F.S. for accurate results.
Fast Response: Equipped with a response time of just 1.0ms (50%), ensuring real-time data for motor testing applications.
Construction: Made from high-quality alloy steel, designed to withstand rigorous testing environments.
Wide Operating Range: Functions effectively in temperatures from -10 to 50°C and humidity levels up to 85% RH.
Reliable Performance: Features a maximum torsion angle of 2.60*10 rad and a safe overload capacity of 150%, ensuring long-term stability and repeatability.

وصف

Specification
Capacity
0-3000N.m
Response time
1.0ms(50%)
Speed signal
1.0-2.0mv/v
Display range
-99999-99999
Zero balance
±2%F.S.
Maximum torsion angle
2.60*10rad(0.149°)
Non-Linearity
0.5%F.S.
Material
Alloy steel
Hysteresis
0.5%F.S.
Stability per year
0.3%/year
Repeatability
0.2%F.S.
Stability per year
0.3%/year
Creep(30min)
0.05%F.S/30min
Load resistance
>2k
Temp effect on output
0.05%F.S./10
Working environment
-10-50 0-85%RH
Temp effect on zero
0.1%F.S./10
Safe Overload
150%
