مميزات خاصة

Voltage Converter DC 12V-90V to 5V step down converter: wide input voltage range 12V-90V( 12V/24V/36V/48V/60V/72V ), output voltage: DC 5V(non-adjustable) 6A 40W
5 Safty Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage; over 100000 hours lifetime, Anti-shock, Anti-humidity, Dust-proof
Die-cast aluminum shell, Silicone sealed, Expoxy potting, Cooling by free air convection, Synchronization rectification technology-multiple intelligent protection function with high conversion efficiency and stability, maximum transfer efficiency of 97% max, low heat generated and Stable performance.
Waterproof rating: IP68, 100% waterproof , can work in rain, waterproof housing makes the converter ideal for use in a wide range of applications including vehicles, security systems, hospital equipment, telecommunications etc, and Commonly used for radio, speaker system, club car, electric bike, solar panel, led lights.
Wide applications: 12V 24V 36V 48V 60V 72V power supply, the DC to DC buck converter can work for electric bike, trucks, LED strip lights, display moniter screen, GPS, RV, car audio system, auto map navigator, electric fan, toy cars, air conditioning

وصف

The dc converter regulator is a high reliability power transformer. It features wide input voltage, low power consumption, high efficiency, high reliability. It can work safely and reliability in 40°C~80°C. It widely used in industrial, automotive, instruments, telecommunication and civil applications.

Die-cast aluminum shell, epoxy potting, cooling by free air convection

5 Safty Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage; Auto-recovery when device is back to normal operating

Stable and reliable performance,

100% waterproof & anti-shock protection, lifetime up to 100,000 hours

Industry grade DC 12V-90V to 5V step-down converter

Synchronization Rectification Technology，efficiency up to 96% max

Ultra compact size, light weight

Non-Isolated Module

Easy to install

Applications: golf cart, forklifts, bus, CMB, large trucks, motor car, solar power generating, bus displaying screen, taxi advertising screen, taxi radio without interference, car audio speaker, LCD TV, LED, intercom and monitor system, etc.

Case material: die-cast aluminum

Potting material: epoxy sealed

Input voltage: 12V 12V 24V 36V 48V 60V 72V DC

Input range: 12V-90V DC

Output voltage: 5V DC

Output current: 6A

Output power: 40W

Efficiency: 97% max

Operating temperature:-40 ~ 80℃

Waterproof rating: IP68

Package included:

1 x DC Voltage converter regulator
