"[Optocoupler Isolation] Ensures safe control of high-voltage devices with isolated low and high-level triggering capability.
[Compact Design] Measures 50 x 41 x 18.5mm, making it easy to integrate into various systems and projects.
[Versatile Control] Supports 5V, 9V, 12V, and 24V power supply options for diverse automation applications.
[User-Friendly Wiring] Clearly labeled terminals for positive, negative, and relay controls simplify installation and setup.
[Dual Channels] Enables control of two devices simultaneously, enhancing efficiency in automation setups.

Features:
The module uses relay, the maximum load of the normally open interface: AC /10A, DC 30V/10A.
Using patch optocoupler isolation, strong driving ability, Durability-Optimized; Actuator current 5mA.
The module working voltage is available in 5V, 9, 12V, 24V.
The module can be triggered by a jumper to set a high level or a low level.
Fault-tolerant design, even if the control line is broken, the relay will not move.
Power indicator (green), relay status indicator (red).
The interface design is user-friendly, all interfaces can be directly connected through the terminal block, very convenient.
Specification:
Module Size:50 x 41 x 18.5mm / 1.97 x 1.61 x 0.73in
Hole Diameter: 3.1mm/0.12in
Hole Interval Distance:44.5 x 35.5mm / 1.75 x 1.4in
Wiring Diagram:
DC+: Connect the positive pole of the power supply (the voltage is required by the relay, there are 5V.9V.12V and 24V selection).
DC-: connected to the negative pole of the power supply.
IN1:1 signal signal Actuator terminal, you can set the high or low level control relay to pull in.
IN2: 2 channel signal Actuator terminal, you can set the high or low level control relay to pull in.
Relay output:
NO1: 1 channel relay normally open interface, the relay is suspended before
