19mm Input Hole Diameter For 750w Servo Motor
HPZS90-L1MA(19-D70-D90-M6) FOR 750W SERVO
Model Number
HPZS90-L1MA
Transmission Ratio
4/5/7/10
Full Load Efficiency
96%
Rated Output Tq (Nm)
80/90/60/39
Rated Input Speed
3000min^-1
Motor Dimensions
19-40/70-3/90-M6
Maximum Input Speed
6000min^-1
Accuracy
10 arcmin
HPZS90-L2MA(19-D70-D90-M6) FOR 750W SERVO
Model Number
HPZS90-L2MA
Transmission Ratio
16/20/25/28/35/40//50/70
Full Load Efficiency
96%
Rated Output Tq (Nm)
90/90/100/90/100/90/100/70
Rated Input Speed
3000min^-1
Motor Dimensions
19-40/70-3/90-M6
Maximum Input Speed
6000min^-1
Accuracy
15 arcmin
14mm Input Hole Diameter For Nema34 Stepper Motor
HPZS90-L1MB(14-D73-D69.6-M5) FOR Nema34 Stepper
Model Number
HPZS90-L1MB
Transmission Ratio
4/5/7/10
Full Load Efficiency
96%
Rated Output Tq (Nm)
80/90/60/39
Rated Input Speed
3000min^-1
Motor Dimensions
19-40/70-3/90-M6
Maximum Input Speed
6000min^-1
Accuracy
10 arcmin
HPZS90-L2MB(14-D73-D69.6-M5) FOR Nema34 Stepper
Model Number
HPZS90-L2MB
Transmission Ratio
16/20/25/28/35/40//50/70
Full Load Efficiency
96%
Rated Output Tq (Nm)
90/90/100/90/100/90/100/70
Rated Input Speed
3000min^-1
Motor Dimensions
19-40/70-3/90-M6
Maximum Input Speed
6000min^-1
Accuracy
15 arcmin
