PSG9060 60MHz Programmable DDS Signal Generator Dual Channels Function Arbitrary WaveformFrequency Meter 300MSa/S Support Phone Control
Data download link:

Model
PSG9060
Channel
2
Sine wave frequency
1nHz-60MHz
Sampling rate
300MSA/S
Wave length
8192 points/channel
Waveformverticalresolution
14 bits
Wave type
Sine
wave, square wave, pulse wave (duty ratio, pulse width and cycle time
can be precisely set), triangle wave, rising ramp, falling ramp, CMOS
wave, DC level, half wave, full wave, positive step wave, Inverse
staircase wave, exponential rise, exponential fall, Lorentz pulse wave,
multisonic wave, random noise wave, trapezoidal pulse wave, Sinker pulse
wave, and 99 sets of user-defined waveforms.
Square wave
1nHz-30MHz
Triangle wave
1nHz-50MHz
Frequencyresolution
1nHz
Rise/Fall Time
10nS
Amplitude range
11MHzFrequency60MHz
2mVpp~25Vpp
2mVpp~10Vpp
2mVpp~5Vpp
Amplitude resolution
1mVpp
Amplitude stability
± 1% ±1mVpp (@ 1kHz,>10mVpp)
Amplitudeflatness
Frequency10MHz:±1%(0.1dB)
Offset range
-9.99V-12.00V
Offset resolution
0.01V
Phase adjustmentrange
0°-359.9°
Phase resolution
0.1°
Outout impedance
50 (typical)
Modulation type
AM,FM,PM,ASK,FSK,PSK,PWM
Trigger
Manual burst, CH2 burst, external burst (AC), external burst (DC)
Measurement function
Frequency, positive and negative pulse width, period, duty cycle
Counter range
0-4294967295
Sweep function
Sweep frequency, sweep amplitude, sweep duty
Sweep mode
Linear, logarithmic
VCOfunction
Frequency control, amplitude control, and duty cycle control
Programmode
Debug and routinely store 100 groups of programs, each with 100 steps
Product dimension
247*243*102mm
Net weight
1038g
Package dimension
340*280*140mm
Gross weight
1900g
1.Signal generator 2.power cable
3.BNC male test lead 4.USB data cable
5.BNC to alligator clips test lead 6.Quick start
==========
Battery Included : No
High-concerned chemical : None
Model Number : PSG9060
Display Size : 2.9 Inches & Under
DIY Supplies : Electrical

Certification : ,FCC
Type : Programmable signal generator
Channel : Dual Channels
Sine Wave Frequency : 1nHz-60MHz
Square Wave Frequency : 1nHz-30MHz
Triangle Wave Frequency : 1nHz-50MHz
Frequency Resolution : 1nHz
Sampling Rate : 300MSA/S
Wave Length : 8192 Points
Vertical Resolution : 14 bits
Sweep Function : Sweep frequency, sweep amplitude, sweep duty
Sweep mode : Linear, logarithmic
Size : 247*243*102mm
Net Weight : 1038g
Gross Weight : 1900g
