【High Power】The mechanism boasts a substantial lifting capacity of 50T, which enables it to lift heavy objects of significant weight with ease. The impressive lifting force renders it a versatile and efficient option for fulfilling various lifting requirements.
【Automatically Retract】The hydraulic lifting cylinder has a built-in extension spring, and the piston can be automatically retracted and reset after the pressure is relieved. The threaded ZG3/8'' quick coupling ensures a tight connection between the hydraulic pump(not included) and the jack.
【Thoughtful Design】The cap at the connecting head can effectively prevent dirty thing from entering the inside of the jack and keep it inside clean. The built-in premium rubber sealing ring can effectively prevent oil leakage and impurities from entering, ensuring good sealing performance of the cylinder.
【Practical Tool】The industrial lifting jack can be operated with a hand pump, foot pump, or electric pump as long as the fittings can be matched.You can also pair it with CP-700A and other manual hydraulic pumps with an oil storage capacity of 0.26 gallons or more and adapt them with the same quick couplings to improve efficiency.
【Application】The 6 inch stroke hydraulic ram cylinder is constructed from high-grade 45# steel, which offers excellent strength and durability. It is commonly used in electric power, chemical, steel, bridge, machinery, and other industries, and is a good helper for assemblers, fabricators, welders, and auto body and frame shops.
وصف
Description
This is a hydraulic cylinder jack with a lifting capacity of 50T. This item is made of high-strength 45# steel and has a strong lifting force that enables it to lift various cumbersome items quickly and firmly. The compact design is not only very portable but also allows it to work in narrow spaces.
Specification
Model: RSC-50150
Color: Yellow
Shape: Cylinder
Material: 45# Steel
Process: Plastic Spraying
Compatible Pumps: CP700A(Not Included)
Total Tonnage: 50T/110231 lbs
Joint Size: ZG3/8"
Stroke: 150mm/5.91in
Piston Diameter: 80mm/3.15in
Cylinder Inner Diameter: 95mm/3.74in
Outer Diameter: 128mm/5.04in
Closed Height: 222mm/8.74in
Package Size: 18*16*26.5cm/7.09*6.3*10.43in
Gross Weight: 20kg/44lbs
Net Weight: 19kg/41.89lbs
