Needle-Bearing
Specification:
Diameter: 22 mm
Channels: 2/3/4/5/6/8 CH
Rated current: 10A
Rated voltage: 220VAC/DC
- Speed: Maximum 200rpm
Working temperature: -20~+60
- Contact material: Gold/Gold
- Wire material: Silver-plated
- Cable length: standard 200mm
- Withstand voltage: 500V 50Hz between two channels
- Insulation resistance: 1000M / 500VDC
- Dynamic resistance fluctuation value: minimum 10m
Shell material: engineering plastic
- Working life: 5 million rpm (depending on working environment and speed)
