Door Types: Suitable for metal doors with a minimum thickness of 1-3/4" (44mm)
Thicker Doors: For doors between 1-3/4" to 2-1/4" thick, specify thickness and order as 31- with a 4-1/2" (114mm) minimum stile width
Rail Sizes: Rails come in four sizes, choose based on door width
Factory Cut Rails: Rails will be cut to size at the factory if door width is provided
E Rail: E Rail fits 24" to 32" door widths, no cutting needed for 32" doors
F Rail: F Rail fits 33" to 36" door widths, no cutting required for 36" doors
J Rail: J Rail fits 37" to 42" door widths, no cutting needed for 42" doors
G Rail: G Rail fits 43" to 48" door widths, no cutting required for 48" doors
Strike: Includes 650 Top Strike & 606 Bottom Strike, rated for panic and fire situations
Dogging Feature: Hex key dogging is standard on non-fire rated devices; specify 16- for #41 cylinder dogging
Electric Options: Choose from various electric options: AL- Alarm, BT- Beacon, PL- SARGuide Photoluminescent Coated, TL- SARGuide Illuminated Touchpad, 53- LX Latchbolt Monitor, 54- Outside Lever Monitoring, 55- Request-to-Exit Signal - Rail Monitoring, 56- Remote Latch Retraction, 57- Delay Egress & Electromagnets, 58- Electric Dogging, 59- Electroguard Self Contained Delayed Egress
Mounting: Machine screws are supplied standard for mounting
Top Bolt: Top bolt is made of stainless steel
Device Centerline: Centerline from finished floor: 41" (1041mm) for standard applications, 38" (965mm) for elementary schools and local accessibility standards with a 100 Series Auxiliary Control
Door/Opening Height: Door/opening height must be specified, with a maximum of 120" (3048mm)
