سارجنت 19-WD8674J-24V ETL RHR BSP جهاز خروج قضيب عمودي مخفي معطف مسحوق الجلد السويدي الأسود in Kuwait

سارجنت 19-WD8674J-24V ETL RHR BSP جهاز خروج قضيب عمودي مخفي معطف مسحوق الجلد السويدي الأسود

KWD 0
– 1 +

مميزات خاصة

  • Door Types: Metal Doors, minimum thickness 1-3/4" (44mm)
  • For thicker doors (1-3/4" to 2-1/4"): Specify thickness, order as 31- with 4-1/2" (114mm) minimum stile width
  • Rails: 4 sizes available, choose based on door width
  • Rails: Factory-cut to size if door width provided
  • E Rail: 24" to 32" door widths, no cutting needed for 32"
  • F Rail: 33" to 36" door widths, no cutting needed for 36"
  • J Rail: 37" to 42" door widths, no cutting needed for 42"
  • G Rail: 43" to 48" door widths, no cutting needed for 48"
  • Strike: 650 Top & 606 Bottom (Panic & Fire Rated)
  • Dogging: Hex key standard on non-fire rated devices; specify 16- for cylinder dogging (#41 cylinder)
  • Electric Options: AL- Alarm, BT- Beacon, PL- SARGuide Photoluminescent, TL- SARGuide Illuminated, 53- LX Latchbolt Monitor, 54- Outside Lever Monitoring, 55- Request-to-Exit Signal, 56- Remote Latch Retraction, 57- Delay Egress & Electromagnets, 58- Electric Dogging, 59- Electroguard Self Contained Delayed Egress
  • Mounting Fasteners: Machine screws supplied standard
  • Top Bolt: Stainless steel
  • Device Centerline: 41" (1041mm) standard, 38" (965mm) for elementary schools & local accessibility standards
  • Door/Opening Height: Specify, max 120" (3048mm)

وصف

Sargent's 19-WD8674J-24V, a concealed vertical rod exit device, finished in black suede powder coat, designed for right-hand reverse doors.
