Rotating axis rotating platform
Gearboxes Gearheads & Speed Reducers
1 Planetary reducer
1Key
4*Install screws
Product parameter
PVF060
PVF090
PVF120
Max. Output Tq
Nm
1.5 Times Rated Output Tq
Instant Braking Tq
Nm
2 Times Rated Output Tq
Max Radial Tq
N
240
450
1240
Max Axis Tq
N
220
430
1000
Torsional Stiffness
Nm/arcmin
1.8
4.85
11
Max Input Speed
rpm
8000
6000
6000
Rated Input Speed
rpm
4000
3500
3500
Noise
dB
58
60
65
Life time
h
20000
Full Load Efficiency
%
L195% L292%
Backlash
PO
L1
arcmin
10
10
10
L2
arcmin
12
12
12
Moment of Inertia
Stage 1 (L1)
3:1
Kg.cm2
0.46
1.73
12.78
4:1
Kg.cm2
0.46
1.73
12.78
5:1
Kg.cm2
0.46
1.73
12.78
7:1
Kg.cm2
0.41
1.42
11.38
10:1
Kg.cm2
0.41
1.42
11.38
Stage 2 (L2)
9:1
Kg.cm2
0.44
1.49
12.18
12:1
Kg.cm2
0.44
1.49
12.18
15:1
Kg.cm2
0.44
1.49
12.18
16:1
Kg.cm2
0.44
1.49
12.18
20:1
Kg.cm2
0.44
1.49
12.18
25:1
Kg.cm2
0.44
1.49
12.18
28:1
Kg.cm2
0.44
1.49
12.18
30:1
Kg.cm2
0.44
1.49
12.18
35:1
Kg.cm2
0.44
1.49
12.18
40:1
Kg.cm2
0.44
1.49
12.18
50:1
Kg.cm2
0.44
1.49
12.18
70:1
Kg.cm2
0.34
1.25
11.48
100:1
Kg.cm2
0.34
1.25
11.48
Parameter
Stage
Ratio
PVF060
PVF090
PVF120
Rated Output Tq (Nm)
Stage 1 (L1)
3:1
27
96
161
4:1
40
122
210
5:1
40
122
210
7:1
34
95
170
10:1
16
56
86
Stage 2 (L2)
9:1
27
96
161
12:1
27
96
161
15:1
27
96
161
16:1
40
122
210
20:1
40
122
210
25:1
40
122
210
28:1
40
122
210
30:1
27
96
161
35:1
40
122
210
40:1
40
122
210
50:1
40
122
210
70:1
34
95
170
100:1
16
56
86
