بيت / ASHCROFT / الضغط والفراغ
محول الضغط، النطاق من 0 إلى 3000 رطل لكل بوصة مربعة، in Kuwait

محول الضغط، النطاق من 0 إلى 3000 رطل لكل بوصة مربعة،

KWD 85
ماركة
ASHCROFT
وزن
454 g
– 1 +

مميزات خاصة

  • <b>Price For:</b> Each <b>Range</b>: 0 to 3000 psi <b>Output - Transmitter</b>: 4 to 20mA DC <b>Lead Length (In.)</b>: 39 <b>Calibration Certificate</b>: - <b>Range Units - Transmitter</b>: psi <b>Item</b>: Pressure Transmitter <b>Output</b>: 4 to 20 mA at 12 to 30VDC <b>Process Connection Size - Transmitter</b>: 1/4" <b>NEMA Rating</b>: - <b>Range Values - Transmitter</b>: 0 to 3000 <b>Features</b>: - <b>Wetted Materials</b>: Stainless Steel
  • <b>Loop Resistance</b>: Dependent on Loop Supply Voltage <b>Accuracy - Transmitter</b>: +/-0.50% Full Scale <b>For Use With</b>: - <b>Process Connection</b>: 1/4" NPT Male <b>Accuracy</b>: +/-0.5% Full Scale <b>Electrical Connections</b>: Shielded Cable <b>Power Required</b>: 9 to 36VDC <b>Transmitter Type</b>: Pressure Transmitter <b>Process Connection Type - Transmitter</b>: MNPT <b>Operating Temp. - Transmitter</b>: -40 Degrees to 257 Degrees F <b>Manufacturers Warranty Length</b>: 1 yr.
  • <b>Includes</b>: Instructions <b>Compatible With</b>: Any Process Compatible with 316Stainless Steel <b>Operating Temp.</b>: -40 to 257 F <b>Electrical Connections - Transmitter</b>: 3 ft. Cable <b>Max. Pressure (PSI)</b>: 6000 <b>Housing</b>: 304 Stainless Steel <b>Thermal Error</b>: +/-3% (-4 Degrees to 185 Degrees F) <b>Wiring Entry - Transmitter</b>: 1/2" FNPT <b>Wetted Materials - Transmitters</b>: Stainless Steel <b>Power Required - Transmitters</b>: 9 to 36VDC
  • <b>Country of Origin (subject to change)</b>: United States

وصف

'Pressure Transmitter, Wetted Materials - Transmitters Stainless Steel, Range Values - Transmitter 0 to 3000, Range Units - Transmitter psi, Accuracy - Transmitter +/-0.50 Percent Full Scale, Electrical Connections - Transmitter 3 ft. Cable, Power Required - Transmitters 9 to 36VDC, Process Connection Size - Transmitter 1/4 In., Process Connection Type - Transmitter MNPT, Output - Transmitter 4 to 20mA DC, Operating Temp. - Transmitter -40 Degrees to 257 Degrees F'
