مميزات خاصة

1.【High-Efficiency 20A Output】Delivers a continuous 20A current, providing reliable and efficient power for a wide range of micro to small-sized RC airplanes and drones, ensuring stable performance during flight.
2.【Integrated 6V/3A Switching BEC】Features a built-in 3A Switching BEC that supplies clean, stable power to your receiver and servos, preventing brown-outs and ensuring glitch-free control of your aircraft's essential electronics.
3.【Ultra-Compact & Lightweight Design】The sleek "Slim" profile and minimal weight allow for easy installation in the tightest of spaces, helping to maintain your model's optimal balance and flight characteristics without adding unnecessary bulk.
4.【Comprehensive Protection Suite】Equipped with multiple safeguards including Low Voltage Cutoff (LVC) and Over-Heat protection, which actively monitor system performance to prevent damage to your ESC, enhancing overall safety and component longevity.
5.【Smooth Operation & Wide Compatibility】Offers smooth throttle response and is compatible with 2-4S LiPo battery setups. It can be easily programmed using ZTW LCD programming card (sold separately) to fine-tune settings for optimal performance with various sensorless brushless motors.

وصف

Key Features:
1. Adopting new generation craft on the MOSFET, low heat generation, withstand large current instantly, and high reliability.
2. Adopting high performance 32 bit microprocessor, stronger computing ability and faster running speed.
3. Super smooth start-up and accurate throttle linearity, higher driving efficiency and more energy-saving.
4. Super strong SBEC output, continuous 6V/3A, peak 5A current, mini size, light weight, good for indoor 3D flying.
5. Multiple protections: start-up, over-heat, low-voltage cutoff, signal loss, phase loss etc.
6. Support high RPM motors, and compatible with most motors in the market.
7. Support programming via LCD program card, easier and more convenient operation.

Specifications:
Model: ZTW Mantis Slim G2 20A
Continuous Current: 20A
Peak Current: 30A
Input Voltage: 2-4S LiPo / 5-12NC
BEC Type: Switching BEC
BEC Output: 6V / 3A
Weight: 14g
Size(L*W*H): 38*16*10mm
Plug: XT60 for battery side/2.0mm Bullet for motor side
Programming Way: Transmitter/ZTW LCD Program Card G2
