Rated Coil Voltage: 24VDC
Max. Operating Current: 75A; Rated coil power: 4.4W
Contact Type: 1 from A (NO); Contact Material: Agsno2
Integrated base design, stable structure, dust resistant
Electrical life: 50000 (Resistive load)

وصف

Specification:

Limit breaking current: 75A, Min:1000mA @ 5DVC
Rated coil voltage: 24VDC
Rated coil power: 4.4W
Contact form: 1 from A (Normally open)
Contact materia: Agsno2
The maximum capacity of the contact contro: 200A
Coil data: 130Ω±10%
The pull in voltag: ≤17VDC
Release voltage: ≥2.4VDC
Operating time: ＜30mS
Release time: ＜15mS
Dielectric voltage (Between coil&conta): 1000VAC, 1min
Electrical life: 50000 (Resistive load)
Mechanical life: 1000000
Ambient temperatur: -40℃～+85℃
