Specifications:
- Diameter: 12.5mm
- Speed: up to 200rpm
- Channel number: 2/4/6/8/12/18 Channels for option
- Rated voltage: 220VAC/DC
- Rated current: 2A/channel
- Operating temperature: -20 ~ +60
- Contact material: Gold/Gold
- Wire length: standard 200mm
- Compressive strength: between the two channels500V 50Hz
- Insulation resistance: 500M/500VDC
- Dynamic resistance fluctuation value: minimum 10m
- Shell material: Engineering plastics
- Working life: 5 million rpm(depending on the working environment and speed)
==========
Hign-concerned Chemical : None
Is Electric : No Battery
Size : Diameter 12.5mm
Model Number : other
Tool Supplies : Assembled class
Remote Control Peripherals/Devices : Slip Ring
Upgrade Parts/Accessories : Electric Collector Rings
RC Parts & Accs : Slip Ring
Material : Composite Material
Use : Vehicles & Remote Control Toys
