Camera Image Sensor: 13 inch progressive scan CMOS Effective Pixels: 2560(H)×1440(V) Signal System: PALNTSC Minimum Illumination: Color: 0.005 Lux @(F1.6, AGC ON),BW: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR WDR: 120Db Day& Night: ICR Digital Zoom: 16× Auto Focus: Auto Semi-automatic Manual Lens Focal Length: 2.8 to 12mm, 4× optical zoom Zoom Speed: Approx. 2s (optical lens, wide-tele) Angle of View: Horizontal field of view: 100 Degree to 33 Degree (Wide-Tele),Vertical field of view: 53 Degree to 18 Degree (Wide-Tele),Diagonal field of view: 119 Degree to 37.5 Degree (Wide-Tele) Minimum Working Distance: 10 to 1500mm (wide-tele) Aperture Range: F1.6 to F2.7 Pan & Tilt Pan Range: 0 Degree to 330 Degree Pan Speed: Configurable, from 0.1 Degree s to 100 Degree s, ,Preset speed: 100 Degree s Tilt Range: Tilt: 0 Degree - 90 Degree Tilt Speed: Configurable, from 0.1 Degree s to 100 Degree s,Preset Speed: 100 Degree s Number of Preset: 300 Infrared IR irradiation distance: 20m IR irradiation angle: Adjustable by zoom Input & Output Audio Input: 1-ch audio input Audio Output: 1-ch audio output Network Ethernet: 10Base -T, 100Base-TX, RJ45 Connector Max.Image Resolution: 2560 × 1440 Video Compression: Main Stream: H.265+H.265H.264+H.264 Audio Compression: G.711ulawG.711alawG.726MP2L2G.722 Audio Mode: OFFAudio inputAudio output General Power Supply: 12 VDC & PoE Power Consumption: Max.: 12 W (Max. 3.9 W for IR) Protection Level: IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection Material: Aluminum alloy, PC, PC+ABS Dimensions: Φ 130.7 mm × 101.7 mm (Φ 5.15 inch × 4.00 inch ) Weight (approx.): Approx. 0.53 kg (1.17 lb)
