156700-1700 12V 20A 5-Pin Mini ISO Automotive RelayDirect replacement by OE number: Compatible with Subaru 82501TC000 (supersedes 82501FE010) and Toyota 90987-04004 / 90084-98032. Crosses: Standard RY-345, Airtex 1R1467, Wells 20129, BWD R4751, Echlin AR485, Pontiac 94858551, DENSO 567-0002.
12V DC, ~20A load rating; 5-pin Mini ISO footprint for common engine/accessory circuits.
Designed to meet OE switching performance for high-current loads with reliable coil actuation.
Housing and terminals sized for factory relay cavities; check cavity orientation/pin layout before install.
Installs in the engine-compartment or passenger-compartment fuse/relay box (location varies by model/year).
Restores proper operation for the circuit assigned to this relay in your vehicle (e.g., daytime running light, accessory, or engine-system loads per application).
Compatible with Subaru: Forester (2003–2021), Impreza (2002–2021), Impreza WRX (2002–2014), Impreza STI (2004–2014), Legacy (2013–2021), Outback (2013–2021), Crosstrek (2016–2021), Ascent (2019–2021), BRZ (2013–2020), WRX (2015–2020).
Also compatible by OE#: Toyota applications calling for 90987-04004 / 90084-98032; Scion FR-S years using 156700-1700; Pontiac Vibe 2009 using 94858551.
1 × 156700-1700 5-Pin Mini ISO relay.
Disconnect the battery negative terminal.
Locate the fuse/relay box; pull the old relay straight up, align pins, and press the new relay fully seated.
Reconnect battery and verify circuit function.
Always confirm by OE number and relay cavity before purchase. Vehicle trims/options can change relay assignments.
