Manufacturer Part Number - UCP207-23
Bearing Insert Type - Radial Ball
Bearing Insert Material - Alloy Steel
Bearing Material Grade – 52100
Shaft Locking Type - Set Screws
Bore Diameter – 1-7/16 in
Bore Diameter Tolerance - +/- 0.0008 in
Mounting Surface to Shaft Center Height - 1-11/64 in
Mount Hole Center-to-Center Length - 5 in
Mount Hole Center-to-Center Width - 5 in
Base Height - 0.708 in
Base Width - 1.889 in
Mount Type - Bolt-Through
Number of Mount Holes – 2
Mounting Bolt Size - 1/2 in
Housing Material - Cast Iron
Housing Material Finish – Painted
Overall Length – 6.574 in
Overall Width – 1.689 in
Overall Height – 3.661 in
Static Radial Load Capacity - 3,439 lbf
Dynamic Radial Load Capacity - 5,777 lbf
Closure - Double Sealed
Seal Type – Contact
Seal Material - Synthetic Rubber
Lubrication Openings - Grease Fitting
Lubricant Material – Grease
Maximum Temperature - 250 °F
Minimum Temperature - -40 °F
Resistance Properties - Corrosion Resistant; Rust Resistant; Wear Resistant
Features - Anti-Rotation Device; Dual Heavy-Duty Slinger Type Contact Seals; Grease Fitting for Adding Lubricant; One-Piece Cast Iron Housing, Solid Base; Standard Duty Unit, Eccentric Locking Collar; Triple Lip Seals Available on Request; Wide Inner Ring Bearing
