Linear Motion Guide Actuators
ER1
Motor 1 not connected or Hall anomaly
Check the connector of motor 1
ER2
Motor 2 not connected or Hall anomaly
Check the connector of motor 2
ER3
Motor 3 not connected or Hall anomaly
Check the connector of motor 3
ER4
Motor 1 phase loss
Check the connector of motor 1
ER5
Motor 2 phase loss
Check the connector of motor 2
ER6
Motor 3 phase loss
Check the connector of motor 3
ER7
Motor 1 blocked or overload
Reset and reduce weight
ER8
Motor 2 blocked or overload
Reset and reduce weight
ER9
Motor 3 blocked or overload
Reset and reduce weight
ERR
Controller hardware error
Replace the controller
E31
Power supply undervoltage or overvoltage
Check the input voltage
E34
Hand control anomaly
Power off and Restart
A01
Motor 1 blocked
Power off and Restart
A02
Motor 2 blocked
Power off and Restart
A03
Motor 3 blocked
Power off and Restart
A08
Controller balancer blocked
Power off and Restart
E09
Controller tilt or 2 columns deviation exceeds 1cm
Check the controller or column
HOT
controller is overheated or works continuously more than 2 min
Wait 18 minutes to rest
LOC
Controller locked
S+V / S+2
A5T
Error
S+V( forced reset)
A5T
Error (S+V/ V unreset)
+ (forced reset)
A5T
Error
V (priority)
==========
Color : black
Torque : 300W
Continuous Current(A) : 2.5A
Construction : Series Wound
Type : Motor
Protect Feature : Totally Enclosed
Commutation :
Efficiency : IE 1
Output Voltage : 60W
voltage : 24-30v
