Linear Sensors
Theory : Resistance Sensor
Material : Metal
Type : vibration sensor
Output : Analog Sensor
Rated load : 1kg
Maximum calibration degree : 2500Nmax
Minimum calibration value : Emax/5000Vmin
Combined error : ±0.030%F.S
Creep : ±0.020%F.S/30min
Effect of temperature on output sensitivity : ±0.021%F.S/10
Effect of temperature on zero output : ±0.028%F.S/10
Output sensitivity : 0.9±0.2mV/V
Input impedance : 406±6
Output impedance : 350±3
Insulation impedance : 5000(50VDC)M
Zero output : 2%F.S
Temperature Compensation Range : -10~+40
Allowed temperature range for use : -35~+70
Recommended excitation voltage : 5~12(DC)V
Maximum excitation voltage : 18(DC)V
Safe overload range : 150%F.S
Limit overload range : 300%F.S
Quadrangle error : 0.02% loading value/100m
