Specification
Intelligent Analytics
AI by Device :Facial recognition, perimeter protection, motion detection 2.0
AI by Camera: Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
Facial Recognition
Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
Face Picture Library: Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4MB, total capacity ≤ 1 GB)
Facial Detection and Analytics Performance: 1-ch, 8 MP
Face Picture Comparison :4-ch
Motion Detection 2.0
By Device: All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
By Camera: All channels
Perimeter Protection
By Device: 2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
By Camera: All channels
Video and Audio
IP Video Input: 8-ch
Incoming Bandwidth: 80 Mbps
Outgoing Bandwidth: 160 Mbps
HDMI Output :1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode: HDMI/VGA independent output
CVBS Output: N/A
Audio Output :1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Two-Way Audio: 1-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding Format: H.265/H.265+/H.264+/H.264
Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback: 8-ch
Decoding Capability: AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps)
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC
Network
Remote Connection: 128
API :ON-VIF (profile S/G); SDK; ISAPI Compatible Browser IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,UPnP, HTTP, HTTPS
Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface :8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power: ≤ 80 W
Standard: IEEE 802.3af/at
Auxiliary Interface
SATA: 2 SATA interfaces
Capacity :Up to 16 TB capacity for each HDD
USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm: In/Out 4/1
General
GUI Language: English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Power Supply: 48 VDC, 2.5 A
Consumption: ≤ 15 W (without HDD, and PoE off)
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10% to 90%
Dimension: (W × D × H) 385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
Weight: ≤ 3 kg (without HDD, 6.6 lb.)
Certification
FCC: Part 15 Subpart B, ANSI C63.4-2014
CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Obtained Certification: CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
