Miniature Cylindrical Connectors
Note:

1. Material.

1. 1 Housing: High temperature thermoplastic with g.f, UL94V-0

1.2 Contact: copper alloy, t=0, 15mm

1.3 Shell: copper .alloy, t=0.25mm

2. Specification:

2:1 Curent rating: 1A Max

2.2 Dielectric withstanding

voltage: 100 V(ac)for 1 min

2.3 Contact resistonce: 30 M Max

2.4 Insulation resistonce: 100 M Min

2.5 Total mating force: 3.57 Kaf Max

2.6 Total unmating force: 1.0 Kgf Min

2.7 Temperature range: -30-80
