Needle-Bearing
Specification:
Diameter: 8.5 mm
- Speed: Maximum 200rpm
Number of channels: 4CH/8CH/12CH
Rated voltage: 220VAC/DC
- Rated current: 1A/channel
Operating temperature: -20~+60
- Contact material: Gold/Gold
- Wire material: Silver-plated
- Cable length: standard 200mm
- Withstand voltage: 500V 50Hz between two channels
- Insulation resistance: 5000M/500VDC
- Dynamic resistance fluctuation value: minimum 10m
Shell material: engineering plastic
- Working life: 5 million rpm (depending on working environment and speed)
