POE48V Power Supply: Integrated Power over Ethernet (PoE) simplifies wiring, supports long-distance stable transmission, complies with IEEE 802.3af standards, offers strong compatibility, and is energy-efficient and environmentally friendly.
Core performance: Equipped with a 1/1.8-inch CMOS sensor IMX415, with a minimum illumination as low as 0.0005 Lux (in color mode), and a wide dynamic range of 120dB, it remains clear in backlit and low-light environments.
Image sensor
1/2.8" 8 million pixel COMS IMX415
Video processing
H.265+/H.265/H.264 video encoding, support code stream 0.1M~12Mpbs adjustable; support frame rate 1~25 frames/second adjustable;
Image output
Main code stream: 3840×2160, 3072×2048, 2592×1944, 2560×1440, 2304×1296, 1920×1080, 1280×720;
Audio interface
1 1 audio input, 1 audio output;
Audio processing
G.711/G711A/AAC audio compression standard, supports two-way voice intercom, supports audio and video synchronization;
Network interface
1 RJ45 Ethernet interface, 10/100M adaptive;
Light board interface
External control mode, requires the corresponding light board to be used together;
Reliability
Business functions
Support OSD, support real-time audio and video transmission, perimeter algorithm detection, dual light source alarm, sound alarm;
Network protocol
Mobile phone monitoring
Power supply
DC12V power input interface;
Working environment
-30~85
Dimensions
2×38(L) * 38(W) (excluding lens)
Bit Depth : 8Bit
Movies File Formats : H.265
Pixels : 8 million
Weight : 301g-400g
NightShot Function : No
Sensor Type : CMOS
Type : Professional
High Definition Support : 4K
Sensor Size : 1/2.8 inches
Use : Professional
CMOS : IMX415
