vibration sensor
Ammeters
AC voltage range: S light off: 48-1000V/ S light status: 12-1000V
Frequency: 50Hz/60Hz
Alarm method: sound and light alarm
Flashlight: white LED illumination
Automatic shutdown: supported
Battery undervoltage reminder indication: supported
Zero line/live line recognition: Based on signal strength signal strength=live line signal weakness=zero line
NCV sensitivity: automatically identifies sensitivity (H M L) in 3
NCD sensitivity indicator light: The tester indicates high/H medium/M low/L through different frequency alarm sounds and different color LEDs
Operating temperature: 0-40
Battery type: 2 * AAA battery (not included)
Product size: 162.9 * 22.2 * 28.3mm
Socket: Not using S high sensitivity function:
Zero line test: The H green light flashes and the buzzer sounds intermittently.
Live line test: H W L three level red light continuous sound of buzzer.
Socket:Using the S high sensitivity function:
Zero line test: The H green light flashes and the buzzer sounds intermittently.
Fire line test: The red light flashes in H W and L gears and the buzzer sounds .
Breakpoint testing:
No breakpoint test: Three gear full red light continuous sound from buzzer
Breakpoint test: From the H red light to the green light the buzzer sounds intermittently.
