57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة in Kuwait 57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة in Kuwait 57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة in Kuwait 57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة in Kuwait 57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة in Kuwait

57BLR50-24-01 Nema23 BLDC المحرك 57 فرش DC 24V 3500RPM 0.23Nm 84W 5.0A Ф57x49mm CNC 1 قطعة

KWD 63.500
– 1 +

مميزات خاصة

  • Pneumatic Motors

وصف

Pneumatic Motors
Manufacturer Part Number: 57BLR50-24-01
Phase: 3
Poles: 4
Rated Voltage: 24V
Rated Speed: 3500±10%RPM
Rated Torque: 0.23Nm(32.57oz.in)
Rated Current: 5±10%A
Rated Power: 84W
Insulation Class: B 130°C[266°F]
Insulation Resistance: 100M Min @500VDC
Dielectric Strength Test: 500VAC for 1 Minute
Frame Size: 57mm
Body Length: 49.1mm
Shaft Diameter: 8mm
Shaft Length: 25mm
Shaft Type: D-cut
D-cut Length: 20mm
Number of Leads: 8
Lead Length: 300mm
Bearing Type: NMB Ball Bearing, C3
Weight: 0.5kg
