Specifications:
Motor Category:-Blower/Fan Motor
Motor Phase:-1 ph
Motor Horsepower:-0.33 hp, 1/3 hp
Synchronous RPM:-1800 rpm
Motor Supply Voltage:-115 V
Frame Size:-48YZ
Enclosure Type:-DP (Drip Proof)
Frequency Rating:-60 Hz
Duty / Condition Type:-Continuous Duty
Mounting Type:-Resilient Base/Extended Studs
Base RPM:-1725 rpm
Thermal Protection:-Automatic
Full Load Current:-5.50 A
Full Load Efficiency:-64.00 %
Shaft Diameter:-0.50 in
Overall Length (C-Dimension):-9.32 in
Frame Material:-Rolled Steel
Insulation Class:-B
IP Rating:-12
Service Factor:-1.35
Standards Met:-UL, CSA
Weight:-15 lbs
Applications:-Blowers, Fans
