[Rapid ​​ Splicing] In 8 seconds, 18 second rapid heating, adjustable time and temperature, 300x magnification for precise cutting angles
[Equipped with 6 Motors] For long distance fiber optic cables, designed for harsh environments with automatic heating shut off
[Mobile App Connectivity] For easy data reading, 10 language options for convenience, high definition 5.0 inch touchscreen
[High Capacity Battery] For 260 times ​ on full charge, usb interface for reverse charging devices like phones
[Vfl Function Support] With 10 wavelengths, self calibration, and large capacity storage, meets a wide range of needs

Spec:
Item Type: Fiber Optic ​ Splicer
Applicable Fiber: SM (G.652 G.657), MM (G.651), DS (G.653), NZDS (G.655) and custom fiber types
Fiber Diameter: Cladding Diameter 80-150um, Coating Diameter 100-1000um
Splicing Loss: 0.02dB (SMF), 0.01dB (MMF), 0.04dB (​/NZDS)
Use ITU-I Clipping Method Measurement
Alignment Method: Fiber Cores, Cladding
Focusing Method: 6 Motor Auto Focusing
Splicing Method: Full Automatic, Semi Automatic, Manual
Splicing Time: 8S (SMF Typical Value)
Pull Test: 1.96N-2.1N
Image Display: 5.0 Inch HD Capacitive Touchscreen, Key or Touch Control, Content Flip Bidirectional Control
Magnification: 300X (X/Y Axes)
Splicing Records: 1000 sets
Typical Heating Time: 18S
Heating Mode: Heating time and temperature adjustable, supports automatic or manual heating
Heat Shrinkable Sleeve: Approx. 20-60mm / 0.8-2.4in
OPM Range (dBm): -70-10dBm, wavelength 850-1650mm (10 bands)
VFL: ≥approx. 15km
Operating Interface: GUI Graphical User Interface
System Upgrade: USB (data export, function upgrade, power output)
Electrode Life: About 3000 Times
Lighting Method: LED
Battery Capacity: 1 x 7800mAh 11.8V Li Battery (typical splicing and heating about 260 times), charging time about 3.5 hours (built in battery)
Working Env
