Sensors
Number of Beams
16/18/20 Pairs
Beams Spacing
40mm
Protection Height
600//680/760mm
Detection Distance
3m as default, can dustomize 5m, 10mz 15m, 20m
Working Voltage
DC/12-24V
Power Consumption
15W
Output
NPN+PNP
Response Time
Housing Material
Aluminum Alloy (yellow)
Detection Method
Through beam
Ambient Temperature
Insulation Resistance
>100MQ
Anti-in terferance
WOOOLux (Angle of incidences 5°)
Connection
M12 connector cable (3 pins with 2 wire)
M12 connector cable (4 pins with 4 wire)
Protection
Reverse connection Protection/ Output short circuit protection
Dielectric Strength
AC1500C.60S
Applicable Temperature
-10°C-55°C
Section Size
35*50mm
MODEL
NUMBER OF BEAMS
SPACING
PROTECT HEIGHT
UPPER COVER HEIGHT
BLIND ZONE
DOWN COVER HEIGHT
TOTAL HEIGHT
D(mm)
H(mm)
A1(mm)
B1(mm)
B2(mm)
A2(mm)
G(mm)
APS50-0440NB
4 40
120
20
20
25
20
205
APS50-0640NB
6 40
200
20
20
25
20
285
APS50-0840NB
8 40
280
20
20
25
20
365
APS50-1040NB
10
40
360
20
20
25
20
445
APS50-1240NB
12
40
440
20
20
25
20
525
APS50-1440NB
14
40
520
20
20
25
20
605
APS50-1640NB
16
40
600
20
20
25
20
685
APS50-1840NB
18
40
680
20
20
25
20
765
APS50-2040NB
20
40
760
20
20
25
20
845
APS50-2240NB
22
40
840
20
20
25
20
925
APS50-2440NB
24
40
920
20
20
25
20
1005
APS50-2640NB
26
40
1000
20
20
25
20
1085
APS50-2840NB
28
40
1080
20
20
25
20
1165
APS50-3040NB
30
40
1160
20
20
25
20
1245
APS50-3240NB
32
40
1240
20
20
25
20
1325
==========
Material : Aluminium alloy
Switch Type : Switch
Warranty : 1 year
Model Number : APS50-1620 APS50-1820 APS50-2020
Item Type : SWITCHES
Beams Spacing : 20mm
Cable length : 2.8 meter
Number of beams : 16/18/20
Detection Distance : 3/5/10/15/20M
Protection Height : 300/340/380
model1 : APS50-1620
model2 : APS50-1820
model3 : APS50-2020
Section Size : 35*50mm
